Highly integrated accessories
COB process
High quality visuals
Die cast aluminum material
The module adopts a hard connection design, making installation convenient and fast;
Intelligent module design, automatically reads and uploads screen calibration data to ensure consistency of the screen after module replacement;
The box is formed by integrated die-casting, with a high-precision lightweight box and a thickness of 39.5mm, effectively reducing the difficulty of screen splicing and transportation costs;
Hidden wiring design between boxes, overall more beautiful;
Free steel structure right angle installation design, suitable for more high-end usage requirements;
The module adopts COB technology, which is moisture-proof and anti-static, to avoid problems such as bright wires caused by damp lamp beads;
Adopting a three in one design of power supply, adapter board (HUB), and receiving card, maintenance is convenient and fast.
Product parameters:
Pixel spacing (mm) 0.9375
Pixel composition 1R1G1B
Module resolution (dots) 160 * 180
Module size (mm) 150 * 168.75
Module surface technology COB, matte matte matte finish
Module surface hardness 4H
The box module consists of 4 columns x 2 rows
Box resolution 640 * 360
Box size (mm) 600 * 37.5 * 39.5
Pixel density (dots/㎡) 1137777
Maintenance method: Full front maintenance
Box material: die cast aluminum
Box flatness ≤ 0.1mm
Grayscale (Bit) 14
White Balance Brightness (nit) 600
Contrast ratio 10000:1
Color gamut ≥ 90% NTSC
Color coordinate standard (0.2870, 0.2955), adjustable
Color temperature (K) standard 9300
Horizontal/vertical viewing angle 160 °/160 °
Chromaticity uniformity ≤ 0.005
Brightness uniformity ≥ 95%
Single point brightness correction support
Single point chromaticity correction support
VTB09H
The module adopts a hard connection design, making installation convenient and fast;
Intelligent module design, automatically reads and uploads screen calibration data to ensure consistency of the screen after module replacement;
The box is formed by integrated die-casting, with a high-precision lightweight box and a thickness of 39.5mm, effectively reducing the difficulty of screen splicing and transportation costs;
Hidden wiring design between boxes, overall more beautiful;
Free steel structure right angle installation design, suitable for more high-end usage requirements;
The module adopts COB technology, which is moisture-proof and anti-static, to avoid problems such as bright wires caused by damp lamp beads;
Adopting a three in one design of power supply, adapter board (HUB), and receiving card, maintenance is convenient and fast.
Product parameters:
Pixel spacing (mm) 1.25
Pixel composition 1R1G1B
Module resolution (dots) 120 * 135
Module size (mm) 150 * 168.75
Module surface technology COB, matte matte matte finish
Module surface hardness 4H
The box module consists of 4 columns x 2 rows
Box resolution 480 * 270
Box size (mm) 600 * 37.5 * 39.5
Pixel density (dots/㎡) 640000
Maintenance method: Full front maintenance
Box material: die cast aluminum
Box flatness ≤ 0.1mm
Grayscale (Bit) 14
White Balance Brightness (nit) 600
Contrast ratio 10000:1
Color gamut ≥ 90% NTSC
Color coordinate standard (0.2870, 0.2955), adjustable
Color temperature (K) standard 9300
Horizontal/vertical viewing angle 160 °/160 °
Chromaticity uniformity ≤ 0.005
Brightness uniformity ≥ 95%
Single point brightness correction support
Grayscale (Bit) 14
VTB12H
The module adopts a hard connection design, making installation convenient and fast;
Intelligent module design, automatically reads and uploads screen calibration data to ensure consistency of the screen after module replacement;
The box is formed by integrated die-casting, with a high-precision lightweight box and a thickness of 39.5mm, effectively reducing the difficulty of screen splicing and transportation costs;
Hidden wiring design between boxes, overall more beautiful;
Free steel structure right angle installation design, suitable for more high-end usage requirements;
The module adopts COB technology, which is moisture-proof and anti-static, to avoid problems such as bright wires caused by damp lamp beads;
Adopting a three in one design of power supply, adapter board (HUB), and receiving card, maintenance is convenient and fast.
Product parameters:
Pixel spacing (mm) 1.56
Pixel composition 1R1G1B
Module resolution (dots) 96 * 108
Module size (mm) 150 * 168.75
Module surface technology COB, matte matte matte finish
Module surface hardness 4H
The box module consists of 4 columns x 2 rows
Box resolution 384 * 216
Box size (mm) 600 * 37.5 * 39.5
Pixel density (dots/㎡) 409600
Maintenance method: Full front maintenance
Box material: die cast aluminum
Box flatness ≤ 0.1mm
Grayscale (Bit) 14
White Balance Brightness (nit) 600
Contrast ratio 10000:1
Color gamut ≥ 90% NTSC
Color coordinate standard (0.2870, 0.2955), adjustable
Color temperature (K) standard 9300
Horizontal/vertical viewing angle 160 °/160 °
Chromaticity uniformity ≤ 0.005
Brightness uniformity ≥ 95%
Single point brightness correction support
Single point chromaticity correction support
VTB15H
